Knife Gate Valves > Non Rising Stem Knife Gate Valves
Non Rising Stem Knife Gate Valve
Model: WAK-GKU75E

Flange Standard: EN1092 PN10
Valve Body: Ductile iron GGG40+Epoxy Powder Coating, Stainless Steel
Knife Material: SS304/SS316/SS2205
Stem Material: SS420/F304/F316
Seat Type: EPDM/NBR/PTFE/Metal to Metal
Operation: Handwheel,Gear,Air actuated,Electric actuated

Connection Standard:
EN1092 PN10
JIS 10K
Other on request.

Max Working pressure:
DN50~DN250:  10Bar
DN300~DN450: 7Bar
DN500~DN600: 4Bar
DN700-DN900: 2Bar
DN1000-DN1200: 1Bar
