Knife Gate Valves > Air Actuated
Air Actuated Knife Gate Valves


Model: WAK-GKU75E

Size: DN50-DN800

Solid One Piece Cast Body, Replacement Seat, Uni directional Type

Designed & Tested to MFS

Operated type:Double acting Cylinder


Materials of construction

Body:Ductile iron GGG40,Stainless Steel,Special materials

Painting: Blue, Black, Red

Knife:SS304,SS316(Solid solution treatment)

Stem:ANSI 1045+CR as standard,17-4PH for optional

Seat: EPDM as standard,NBR,PTFE,Viton,Metal

Connection: EN1092 PN10, JIS 10K
